The pure white colour option lends itself well to interiors based around timeless neutral hues where an understated seamless look is desired.
R32 is a refrigerant with just one-third the global warming potential of R410A and has zero ozone depletion potential. R32 offers increased energy efficiency, and is said to be the next generation of refrigerants
For the ultimate in aesthetics and heat pump control no matter where you are, this unit comes equipped with a Wi-Fi Interface inside a hidden pocket in the indoor unit.
The heat exchanger of the outdoor has been treated with Blue Fin anti-corrosion treatment slowing the corrosion process caused by salt and sulphur in the air especially in coastal and high sulphur areas.
With an advanced “Silent Mode” fan setting, the range starts from a super quiet 19dBA*. Allowing you to enjoy quiet, yet powerful performance.
*EF 25 indoor on lowest fan speed in cooling mode.
The extra-large, washable 3D filter surface incorporates nanometre-sized platinum-ceramic particles designed to effectively collect fine dust particles, deodorise the air and eliminate bacteria at the same time. This level of advanced filtration is better at the collection of dust in comparison to conventional filters.
The Designer Series with its distinctive contemporary, slim-line profile has been awarded the Prestigious Reddot Design Award 2015 in recognition for outstanding design quality.
The international jury only confers this sought-after seal of quality to products that set themselves apart significantly from comparable products thanks to their excellent design.
The Backlit 7-Day Programmable Controller features a built-in weekly timer, allowing you to program up to four time and temperature settings for each day of the week. You can now return to comfort without having to manually adjust the temperature. Perfect for anyone with a busy lifestyle, the Backlit 7-Day Controller is a great way to regulate your energy usage without compromising on comfort.
Designed to integrate with your existing Heat Pump, this high-performance two-stage advanced air filtration module, cleans and minimises dust and other allergens for better indoor air quality, all year round.
Learn more
| · | Function: Cooling/Heating | · | Type: Single Split, Inverter |
| Rated | |||
| · | Capacity - Cooling: 4.2 kW | · | Capacity - Heating: 5.4 kW |
| · | Capacity - Cooling (min. - max.): 0.9 - 4.6 kW | · | Capacity - Heating (min. - max.): 1.3 - 6.3 kW |
| · | Power Input - Cooling: 1.2 kW | · | Power Input - Heating: 1.455 kW |
| · | Current - Cooling [In+Outdoor] (Rated): 5.40 A | · | Current - Heating [In+Outdoor] (Rated): 6.50 A |
| Energy Rating Residential | |||
| · | ZERL - Cooling (Cold/Mixed/Hot): 3.0 / 3.0 / 3.0 | · | ZERL - Heating (Cold/Mixed/Hot): 2.0 / 2.5 / 3.0 |
| · | TCSPF (Cold/Mixed/Hot): 4.70 / 4.50 / 4.73 | · | HSPF (Cold/Mixed/Hot): 3.55 / 4.07 / 4.58 |
| · | EER / COP: 3.50 / 3.71 | · | AEER / ACOP: 3.49 / 3.70 |
| Energy Rating Commercial | |||
| · | TCSPF (Cold/Mixed/Hot): 5.52 / 5.15 / 5.03 | · | HSPF (Cold/Mixed/Hot): 3.83 / 4.28 / 4.59 |
| Performance | |||
| · | Operation Range - Cooling: -10 / +46 degC | · | Operation Range - Heating: -15 / +24 degC |
| · | Function: Cooling/Heating | · | Type: Single Split, Inverter |
| Nominal Capacity | |||
| · | Capacity - Cooling: 4.2 kW | · | Capacity - Heating: 5.4 kW |
| · | Sound Level - Cooling (Silent - Super High, dB(A)): 28 / 31 / 35 / 39 / 43 | · | Sound Level - Heating (Silent - Super High, dB(A)): 28 / 30 / 35 / 41 / 48 |
| · | Air Volume - Cooling (Super High, Litre/sec): 187 | · | Air Volume - Heating (Super High, Litre/sec): 220 |
| · | Refrigerant: R32 | · | Liquid Pipe Size (OD, mm): 6.35 |
| · | Gas Pipe Size (OD, mm): 9.52 | · | Max. Pipe Length (m): 20 |
| · | Max. Pipe Height (m): 12 | · | Power Supply: 230V / Single Phase / 50/60 Hz |
| · | Dimensions (WxDxH, mm): 885 x 195 x 299 | · | Weight: 11.5 kg |
| · | Function: Cooling/Heating | · | Type: Single Split, Standard Inverter |
| · | Operation Range - Cooling: -10 / +46 degC | · | Operation Range - Heating: -15 / +24 degC |
| · | Sound Level - Cooling (dB(A)): 50 | · | Sound Level - Heating (dB(A)): 51 |
| · | Air Volume - Cooling (Litre/sec): 572 | · | Air Volume - Heating (Litre/sec): 545 |
| · | Power Supply: Single phase, 230 V, 50/60Hz | · | Refrigerant: R32 |
| · | Liquid Pipe Size (OD, mm): 6.35 | · | Gas Pipe Size (OD, mm): 9.52 |
| · | Max. Pipe Length (m): 20 | · | Max. Pipe Height (m): 12 |
| · | Dimensions (WxDxH, mm): 800 x 285 x 550 | · | Weight: 35 kg |
