CMB-P V-KA // Mitsubishi Electric

CMB-P V-KA

Main Branch Controller
Can Connect To Sub Branch Controller
16 Branch
Connects to 200-1100 model

This main range of R410A VRF Branch Controllers (BC) feature solenoid and linear expansion valves allowing connection to up to 16 indoor units.
R410A refrigerant is used between the BC, the outdoor unit and the indoor units. Branch controllers are exclusively compatible with R410A VRF heating and cooling outdoor/condensing units, enabling simultaneous heating and cooling with heat recovery. This allows one zone to be heated while another is cooled, with recovered heat energy transferred between zones rather than expelled outdoors and wasted.
The horizontal configuration allows for ceiling installation above hallways or foyers.
