QAHV-N560YA-HPB For Large Capacity Hot Water Applications QAHV Hot Water Heat Pump
As a leading manufacturer of air-to-water heat pumps, Mitsubishi Electric have developed QAHV; the latest innovation in their comprehensive lineup of Hot Water Heat Pump products. QAHV has been specifically designed to produce high volume hot water and is suitable for commercial and industrial applications where hot water demand is high. By adopting Mitsubishi Electric's unique technology, QAHV ensures highly reliable performance as well as high heating capacity even at low outdoor temperatures. QAHV Hot Water Heat Pump Series * Under normal heating conditions at outdoor temp:16ºCDB/12ºCWB, inlet water temp 17ºC, outlet water temp 65ºC Main Features of QAHV • Utilises natural refrigerant (CO2) • High efficiency (Achieved COP 3.88*) • Supplies high temperature hot water of up to 90ºC • Operable even at low outdoor temperature of -25ºC Increased Energy Savings Unique to Mitsubishi Electric, QAHV utilises a twisted and spiral gas cooler. Using twisted pipes as water pipes and running the refrigerant pipes along their grooves helps to increase the heat-conductive area; allowing for better heat transfer and an impressive COP of 3.88*. The continuous spiral groove design accelerates the turbulence effect of water and helps to reduce pressure loss within the heat exchanger, enhancing efficiency. Equipped with the latest inverter scroll compressor, QAHV offers unparalleled efficiency when compared to fixed speed systems. Superior Heating Performance in Low Temperatures QAHV is able to provide its full heating capacity of 40kW even at ambient temperatures as low as -3°C. Furthermore, the unit operates to supply 90°C hot water in ambient temperatures as low as -25°C. This superior level of performance is achieved using Mitsubishi Electric’s industry-first Flash Injection Circuit which provides the optimum amount of refrigerant to the system via a compressor through a specially designed injection port, ensuring highly stable operation. Why is CO2 Refrigerant Used? QAHV adopts CO2 (R744) as it is an environmentally-friendly, natural refrigerant which has zero Ozone Depletion Potential (ODP) and has a Global Warming Potential (GWP) of 1. Ideal Applications Gyms Hotels Motels Aged Care Facilities Schools Universities
Mitsubishi Electric Patented Twisted and Spiral Gas Cooler Stable Heating Capacity Even at Low Temperatures QAHV System Schematic Image Using twist pipes as water pipes and running the refrigerant pipes along their grooves helps to increase the heat-conductive area, allowing for better heat transfer. Illustration showing water flow and water temperature distribution Twisted water pipe with the refrigerant pipe spiralled around it Cut section detail HOT COLD Water Outlet COMP. LEV Air Side HEX Water Side HEX Refrigerant HEX LEV Air Refrigerant HEX Highly efficient inverter-driven CO2 s c r o l l compressor Oil HEX Water Inlet Flash Injection Circuit Capacity [KW] Outdoor Temp. [ºCDB] -30 -25 -10 -3 0 30 50 40 20 15 Full heating capacity even at -3°C Operable as low as -25°C 1 QAHV 2 Remote Controller (optional) Hermetic Type Storage Tank Representative Water Temp. Sensor (optional) Inlet Water Mains Water Outlet Hot Water Piping Inlet Water Piping Control Wiring
Optional Parts For more information on Mitsubishi Electric Heat Pumps, please visit www.mitsubishi-electric.co.nz or call our Customer Service Team on 0800 784 382 AUCKLAND BRANCH Unit 1, 4 Walls Road PO Box 12726 Penrose, Auckland 1642 Phone (09) 526 9347 CHRISTCHURCH BRANCH 44 Halwyn Drive PO Box 16904 Hornby, Christchurch 8441 Phone (03) 341 2837 WELLINGTON HEAD OFFICE 1 Parliament Street PO Box 30772 Lower Hutt 5040 Phone (04) 560 9147 Fax (04) 560 9133 Black Diamond Technologies Exclusive distributor of Mitsubishi Electric products in NZ Be sure to ask for Mitsubishi Electric. Other brands share the 3-diamond logo, however they are separate to the Mitsubishi Electric brand and cannot supply the models, features or guarantees outlined in this brochure. | All models, features and specifications are subject to change and amendment at anytime. Printed August 2018. Notes: *1.Under Normal heating conditions at the outdoor temp, 16°CDB/12°CWB(60.8°FDB/53.6°FWB), the outlet water temperature 65°C(149°F), and the inlet water temperature 17°C(62.6°F) *2.Under Normal heating conditions at the outdoor temp, 7°CDB/6°CWB(44.6°FDB/42.8°FWB), the outlet water temperature 65°C(149°F), and the inlet water temperature 9°C(48.2°F) *3.Under Normal heating conditions at the outdoor temp, 7°CDB/6°CWB(44.6°FDB/42.8°FWB), the outlet water temperature 65°C(149°F), and the inlet water temperature 15°C(59.0°F) *4.Under Normal heating conditions at the outdoor temp, 7°CDB/6°CWB(44.6°FDB/42.8°FWB), when the unit is set to the “Capacity Priority“ mode through the dry NC-contact. *Due to continuing improvements, specifications may be subject to change without notice *Do not use steel pipes as water pipes. *Keep the water circulated at all times. Blow the water out of the pipes if the unit will not be used for an extended period time. *Do not use ground water or well water *Do not install the unit in an environment where the wet bulb temperature exceeds 32°C *The water circuit must use the closed circuit *There is a possibility that the unit may abnormally stop when it operates outside its operating range. Provide backup (ex. boiler start with error display output signal (blue CN511 1-3)) for abnormal stop. UNIT CONVERTER BTU/h = kW x 3,412 cfm =m3/min x 35.31 lbs = kg/0.4536 QAHV-N560YA-HPB Power Source 3-phase 4-wire 380-400-415V 50Hz Capacity *1 kW 40 Btu/h 136480 Power Input kW 10.31 Current Input A 17.8-16.9-16.3 COP(kW/kW) 3.88 Capacity *2 kW 40 Btu/h 136480 Power Input kW 10.97 Current Input A 20.0-19.0-18.3 COP(kW/kW) 3.65 Capacity *3 kW 40 Btu/h 136480 Power Input kW 11.6 Current Input A 20.4-19.4-18.7 COP(kW/kW) 3.44 Maximum Current Input *4 A 28.8-27.4-26.4 Allowable External Pump Head 77kPa Temperature Range Outlet Water Temp 55–90°C (when the secondary side control is enabled: 55–80°C) Outdoor Temp D.B. -25~43°C Sound Pressure Level (measured 1m below the unit in an anechoic room) *1 dB(A) 56 Water Pipe Diameter and Type Inlet mm(in.) 19.05(Rc 3/4"), screw pipe Outlet mm(in.) 19.05(Rc 3/4"), screw pipe External Finish Acrylic painted steel plate <MUNSELL 5Y 8/1 or similar> External Dimension H x W x D mm 1837(1777 not including legs) x 1220 x 760 Net Weight kg(lbs) 400(882) Design Pressure R744 MPa 14 Water MPa 1.0 Heat Exchanger Water-side Copper tube coil Air-side Plate fin and copper tube Compressor Type Inverter scroll hermetic compressor Maker MITSUBISHI ELECTRIC CORPORATION Motor Output kW 11.0 Case Heater kW 0.045 FAN Air Flow Rate m3/min 220 L/s 3666 Type x Quantity Propeller fan Control, Driving Mechanism Inverter-control, Direct-driven by motor Motor Output kW 0.92 HIC (HIC: Heat inter-changer) Circuit Copper pipe Protection High Pressure Protection High pres.Sensor & High pres. Switch at 14MPa(643psi) Inverter Circuit Overheat and overcurrent protection Compressor Overheat protection Fan Motor Thermal switch Defrosting Method Auto-defrost mode (Hot gas) Refrigerant Type x Original Charge CO2 (R744) 6.5kg Remote Controller PAR-W31MAA-J Representative Water Temperature Sensor TW-TH16-E
