Super-Efficient Next Generation Domestic Hot Water Technology QUHZ Ecodan CO2 Advanced Hot Water Heat Pump
3 Evaporator Water heat exchanger Evaporator Water heat exchanger Expansion valve Compressor Heat Hot-water outlet Expansion valve expands refrigerant to lower the temperature Refrigerant compressed to raise the temperature Heat absorbed from the air 4kW 3kW Electrical energy input 1kW Air-to-water heat pump principle （when heating） Refrigerant and heat circulation 〈Case of COP 4.0〉 Produces 4 times the amount of energy input 1kW Electrical Energy input 3kW Heat absorbed from the Air 4kW Heat outlet ＋ ＝ On average, domestic hot water accounts for over 36%*1 of the overall energy bill in New Zealand homes. Domestic hot water heating is therefore an obvious area to target in reducing energy bills. This is especially pertinent during the winter months, where a combination of taking longer, hotter showers and the increased need for a warm and dry home, typically drives up power bills. An Ecodan CO2 Hot Water Heat Pump System can help reduce hot water bills when compared to gas and direct electric systems. What is an Ecodan CO2 Hot Water Heat Pump? The Ecodan CO2 Heat Pump is an advanced heat pump system that can either combine the hot water heating supply and room heating for a small apartment, or provide the complete hot water heating requirements for a typical 4 person household. Why CO2? CO2 is used as the refrigerant in this product because it is a naturally occurring gas. Recent technical advances in heat pump technology have allowed us to harness this gas which would have no adverse effect on the environment should it ever leak into the atmosphere, unlike other refrigerants which have the potential to add to global warming in the unlikely event that they ever leak. CO2 (R744) is a safe, naturally occurring (0.04%) of atmosphere, non-flammable and stable refrigerant fluid solution. It is non-toxic (at reasonable concentrations) and with a Global Warming Potential (GWP) number of 1, it is also the base refrigerant that all other refrigerants GWP numbers are based on. Mitsubishi Electric has utilised their expertise and industry-leading technology to develop Ecodan CO2 Hot Water Heat Pumps. The system has been specifically designed to provide all the super energy efficient hot water heating requirements for a household of up to 4 people, or alternatively can also be used to provide both space heating for a small one bedroom apartment as well as covering its hot water requirements at the same time. Ecodan CO2 Advanced Hot Water Heat Pumps Super-Efficient Next Generation Technology COP Comparison Chart Electric Heating Ecodan Gas Heating (Non-Condensing) 0.82 0.99 4.00 What is a Hot Water Heat Pump Heat pumps use electrical energy and take low grade heat energy from the outdoor air to heat refrigerant which in turn heats water for domestic use and space heating. The efficiency of a heat pump is known as the Coefficient of Performance or COP. This is a ratio of the heat delivered to power consumed. For every 1kW of electrical input energy, Ecodan absorbs renewable heat energy from the outdoor air to provide the home with over 4kW*2 of heat output. Compared to typical gas and direct electric heating systems that can have higher running costs with COPs as low as 0.82*3, Ecodan provides an energy efficient alternative. *1 Based on data sourced from NZGBC. *2 The overall system efficiency and energy savings will depend on the comparison with your current heating system, satisfactory system design and installation, and operational settings i.e. how you use the heating system. *3 Based on manufacturer information for gas instant hot water heater (non-condensing).. 2
The Ecodan QUHZ Advantage The Ecodan QUHZ has been specifically designed to operate with exceptionally high efficiency in the production of hot water. The system operates with a market leading low noise output and built in energy monitoring is standard. Rated at 4kW the Ecodan QUHZ is ideal to satistfy the hot water requirements for new build homes and can also be retro-fitted in existing homes. Alternatively, it can also provide both domestic hot water and room heating for small one bedroom apartments. 80dBA Subway car interior Sound of rustling leaves Human hearing limits (Extremely quiet) Quiet passenger car Interior (40km/h) Library interior 60dBA 40dBA 10dBA Only 43dBA Industry Leading Low Noise Operation The Ecodan QUHZ operates with an industry leading low noise output. Specific outdoor unit design features enable quiet operation to be maintained in all modes of operation and all ambient conditions. Low noise output also allows improved flexibility in the installation location of the heat pump. The Ecodan QUHZ will help residential areas that are particularly sensitive to outdoor noise to benefit from renewable heating technology. • High efficiency domestic hot water production COP=3.7* • Class leading low noise operation at 43dBA outdoor unit • Energy monitoring as standard • No stored water draw, no risk of legionella • High hot water capacity for larger dwellings up to 70°C • Pre-plumbed and wired for faster installation • No refrigerant pipework into the house, water connections only Key Features Ideal for High Density Housing With space often being a premium on new build development sites, Ecodan QUHZ will operate discreetly where dwellings are in close proximity to each other. The QUHZ Outdoor unit provides very quiet operation as low as 43dBA (SPL)** & 53dBA (PWL). ** Measured at 1m from the front of the outdoor unit. * Under heating conditions; outdoor temperature 7ºC, water outlet temperature 65ºC, flow rate 1.4L/min.
The Ecodan QUHZ is Mitsubishi Electric’s latest hot water heat pump system and is the ideal solution for both new build and existing homes. The Ecodan QUHZ has been specifically designed to operate with exceptionally high efficiency in the production of hot water. Mitsubishi Electric Unique Heat Exchange Technology Greater Flexibility and Enhanced Efficiency Using a thermal store allows greater flexibility and enhanced efficiency when applying Ecodan QUHZ to different types of homes. Varying the setpoint of the thermal store, and how much of the store is heated, ensures the correct amount of hot water is produced for the home. See the example on the right. The Thermal Store Explained • The Ecodan QUHZ provides hot water to the home using a dedicated pre-plumbed 200 litre thermal store. • The thermal store is specifically designed to enable efficient production of hot water for a household of up to 4 people and uses advanced control logic to provide optimum performance at all times. • The Ecodan QUHZ Outdoor unit is connected to the thermal store by a sealed primary circuit. • Mains cold water is heated instantaneously as it passes through a plate heat exchanger and the hot water produced is sent directly to the outlets ready to use. • As domestic hot water is not stored in the system there is no risk of legionella associated with traditional hot water tanks. Greater Flexibility and Enhanced Efficiency Example Four Person Household One Bedroom Apartment 4
6 Original hot water supply system Thanks to the original hot water supply system, primary circuit keeps airtight and legionella bacteria seldom grows, thus no need for legionella prevention mode. Variable hot water storage volume Stratification within the tank can be kept properly because hot water stores from top of thermal store tank. QUHZ can choose hot water storage volume (E. Save/ Normal). When the DHW storage volume shows a decrease of 50 L from the DHW max. amount, DHW mode operates and the flow from the primary heating circuit is diverted to heat the water in the thermal store tank. When the amount of the stored hot water reaches the DHW max. amount or if the DHW max. operation time set by the installer is exceeded DHW mode ceases to operate. Heat pump 150L Heat pump 100L Heat pump 150L Heat pump 200L Heat pump DHW Inner view Outer view Thermal store tank Plate heat exchanger DHW Storage Volume DHW max. amount DHW restart amount E. Save Normal Unique Twisted & Spiral Gas Cooler to Maximise Heat Transfer The twisted & spiral gas cooler (heat exchanger) is Mitsubishi Electric's unique technology. Three connected refrigerant pipes are wound around the twisted water pipe which maximises the heat transfer area. Twisted water pipe with the refrigerant pipe spiralled around it Cut section detail HOT COLD Enhanced Water Flow Whilst Maintaining Optimum Water Pressure The continuous spiral grooves in the twisted pipe accelerates the turbulence effect of water and also helps to reduce pressure loss within the heat exchanger. Optimum Water Temperature is Maintained This system uses a heat store rather than potable stored water to enable good stratification of the heat store which maintains the systems efficiency and allows fresh cold water to be instantly heated up through the integrated heat exchanger which will eliminate any potential issues with legionella associated with traditional stored water systems in the tank. Mode Selection The user can select a mode to suit usage and occupancy. In Normal Mode the system stores enough heat to deliver around 250L of hot water, in E.Save Mode the system will store enough heat to deliver around 120L of hot water. When the Domestic Hot Water (DHW) storage volume shows a decrease of 50L from the DHW max. amount, DHW Mode operates and the flow from the primary heating circuit is diverted to heat the water in the thermal store tank.
QUHZ-W40VA Key Features • High efficiency hot water heating performance • Class leading, low noise operation at 43dBA • Quietest outdoor unit in New Zealand • Small outdoor unit, reduced footprint • Lightweight outdoor unit Ecodan QUHZ Outdoor Unit ECODAN QUHZ Rated at 4kW the Ecodan QUHZ is ideal to satistfy the hot water requirements for a new build home and can also be retro-fitted in existing homes. Alternatively, it can also provide both hot water heating and room heating for one bedroom apartments. OUTDOOR UNIT QUHZ-W40VA NOMINAL WATER FLOW RATE (HEATING MODE) L/min 5.7 HEATING (A7/W35)*1 Capacity kW 4 COP 4.2 Power input kW 0.96 HEATING (A2/W35)*2 Capacity kW 4 COP 3.1 Power input kW 1.3 NOMINAL WATER FLOW RATE (DHW MODE) L/min 1.4 DHW (A7/W65)*3 Capacity kW 5 COP 3.7 Power Input kW 1.35 POWER SUPPLY (PHASE, CYCLE, VOLTAGE) Max. current A 12.0 BREAKER SIZE - EXTERNAL FINISH Munsell 2.5Y 7/1 HEAT EXCHANGER Air Plate fin coil Water Twisted & spiral Gas cooler FAN Fan (drive) x No. Propeller fan x1 Fan motor output kW 0.050 Air flow m3/min 34 (MAX) NOISE LEVEL (SPL) Heating dBA 43 NOISE LEVEL (PWL) Heating dBA 53 DIMENSIONS (mm) Width mm 809 + (70)*4 Depth mm 300 + (20)*5 Height mm 715 WEIGHT kg 57 REFRIGERANT R744 Quantity kg 1.15 WATER PIPE SIZE O.D mm 22 PIPE CONNECTION G1/2 PIPEWORK BETWEEN THE INDOOR & OUTDOOR Max. Height difference m 5 Max. Piping length m 15 GUARANTEED OPERATING RANGE (OUTDOOR) Heating ºC -15 ~ +35 OUTLET WATER TEMP. (MAX. IN HEATING) Heating ºC +60 OUTLET WATER TEMP. (MAX. IN HOT WATER) DHW ºC +72 NOMINAL RETURN WATER TEMPERATURE RANGE Heating ºC +9 ~ +55 WATER FLOW RATE RANGE (HEATING) L/min 3.0 ~ 8.0 *1 Under nominal operating conditions: Outdoor temp 7°CDB / 6°CWB, outlet water temp 35°C, inlet water temp 25°C *2 Under nominal operating conditions: Outdoor temp 2°CDB / 1°CWB, outlet water temp 35°C, inlet water temp 25°C *3 Under nominal operating conditions: Outdoor temp 7°CDB / 6°CWB, outlet water temp 65°C, inlet water temp 15°C *4 Piping cover *5 Wire grille 6
Key Features • 70ºC domestic hot water • Energy monitoring as standard • Pre-plumbed and wired for faster installation • No stored water, no risk of legionella • High hot water capacity for large dwellings Ecodan QUHZ Cylinder THERMAL STORE The Ecodan QUHZ provides hot water to the home using a dedicated preplumbed 200 litre thermal store. The thermal store is specifically designed to enable efficient production of hot water and space heating and uses advanced control logic to provide optimum performance at all times. EHPT20Q-VM2EA INDOOR UNIT EHPT20Q-VM2EA NOMINAL THERMAL STORE TANK VOLUME L 200 OVERALL UNIT DIMENSIONS mm 1600 x 595 x 680 (Height x Width x Depth) WEIGHT (EMPTY) kg 77 WEIGHT (FULL) kg 283 PRIMARY EXPANSION VESSEL (ACCESSORY ITEM) Nominal volume L 18 Charge pressure bar/kPa 1.0 (100) SAFETY DEVICE Water circuit (Thermal store tank) Control thermistor (THW1) ºC 42 - 72 Control thermistor (THW3) ºC 80 Pressure relief valve (2 No. devices) bar/kPa 3.0 (300) Flow sensor min flow L/min Min flow 1.3 Manual reset thermostat ºC 90 Booster heater Manual reset thermostat ºC 90 Thermal Cut-out (for dry run prevention) ºC 121 CONNECTIONS Primary circuit mm Ø 22.0 Secondary (potable) circuit mm Ø 22.0 TARGET TEMPERATURE RANGE Space heating Flow temperature*1 ºC 25 - 60 Room temperature ºC 10 - 30 DHW supply temperature range ºC 40 - 70 GUARANTEED OPERATING RANGE Ambient*2 ºC 0 - 35 (80%RH) Outdoor temperature ºC -15 ~ +35 ELECTRICAL DATA Control board Power supply (Phase, voltage, frequency) single / 230V / 50 Hz Current A 12.8 Breaker (Local supply) A 20 Booster heater Power supply (Phase, voltage, frequency) single / 230V / 50 Hz Capacity kW 2 Current A 8.7 Breaker A 16 SOUND POWER LEVEL dBA 40 MAXIMUM SECONDARY (POTABLE) WATER SUPPLY PRESSURE bar/kPa 10 (1000) MAXIMUM PRIMARY WORKING PRESSURE bar/kPa 2.5 (250) MINIMUM PRIMARY WORKING PRESSURE bar/kPa 1.0 (100) *1 Depending on the ambient conditions, it may not reach the set temperature, please refer to the databook. *2 The cylinder's environment MUST be frost-free. 7
Full 5 Year Warranty Every Ecodan Air Source Heat Pump comes with a full 5 year warranty as standard, subject to the following conditions: • The Ecodan purchase and installation is registered with BDT. • The Ecodan must be installed and commissioned by a trained BDT Installer. Manufactured in Japan The Mitsubishi Electric manufacturing facility in Gunma, Japan produces the QUHZ Hot Water Heat Pump and Cylinder System for the global market. Member of the NZGBC The New Zealand Green Building Council (NZGBC) is a non-profit membership organisation that promotes better buildings. Thousands of buildings are being constructed, providing healthier and happier workplaces and homes for thousands of Kiwis. 5years Parts | Labour FIVE YEAR WARRANTY MITSUBISHI ELECTRIC QUALITY FOR PEACE OF MIND For more information please visit our website or call our Customer Service Team. www.mitsubishi-electric.co.nz | 0800 784 382 PRINTED May 2021
