OmniCore Multi Room Heat Pump Systems

Multi Room Heat Pump Systems The perfect heat pump for each room with just one OmniCore outdoor unit

Mitsubishi Electric OmniCore Multi Room Heat Pump Systems allow you to choose the perfect heat pump for each room, up to eight, without the need to install multiple outdoor units – with OmniCore you only need one. Whether it is a small capacity whisper quiet high wall for the bedroom, a compact floor console for the home office or a discreet ducted model for the lounge, there is a style and capacity to fit any room. The choice is truly yours. Our extended OmniCore Multi Room Heat Pump Range now offers a wide selection of market-leading solutions. OMNICORE – THE HEART OF MULTI ROOM

About OmniCore Multi Room Heat Pump Systems ................................. 2 Add Optional Lossnay Ventilation ............................................................ 4 Choosing the Right Heat Pumps for Your Home ..................................... 6 OmniCore Multi Room Series Outdoor Units ........................................... 8 OmniCore Classic Multi Series and OmniCore Pro Multi Series OmniCore Multi Room Indoor Unit Compatibility Chart ........................ 10 EcoCore AP Series ............................................. 12 High Wall Designer EF Series ............................................. 15 High Wall Black Diamond LN Series.................................... 16 High Wall RapidHeat KW Series ..........................................18 Floor Console PFFY Series ........................................................ 20 Concealed Floor Console SEZ Series .......................................................... 21 Ceiling Concealed PEFY Series ........................................................ 22 Ducted PEAD Series ........................................................ 24 Ducted SlimFit MLZ Series .............................................. 25 One-Way Ceiling Cassette SLZ Series .......................................................... 26 Compact Ceiling Cassette PLA Series .......................................................... 27 Ceiling Cassette PCA Series .......................................................... 28 Under-Ceiling Specifications ......................................................................................... 29 Controllers .............................................................................................. 30 Wi-Fi Control, Handheld, Wall Mounted, Central, and Zone Control Lossnay Fresh Air Heat Recovery Ventilation ........................................ 32 Your OmniCore Multi Room Heat Pump Recommendation .................. 33 Contents 1

The Total Home Solution An OmniCore Multi Room Heat Pump System not only gives you the freedom to select the indoor model best suited to each and every room in your home, it also enhances exterior aesthetics by reducing the number of outdoor units required. With an OmniCore Multi Room Heat Pump System you have the freedom to choose the ideal unit for each area of your home, keeping you comfortable without cluttering the exterior. With Mitsubishi Electric Heat Pump Technology, you also get the benefit of superior efficiency and energy savings. Only one outdoor unit Choose from High Walls, Floor Consoles, Ducted or Cassettes Energy efficient From 1 to 8 room solutions Whisper quiet Optional Wi-Fi Control Optional Zone Control (Ducted indoors only) What is an OmniCore Multi Room System? While a standard heat pump system consists of a single indoor and outdoor unit, an OmniCore Multi Room Heat Pump System allows you to connect multiple indoor units to a single outdoor unit. Ceiling Cassette Ducted Ceiling Concealed Floor Console High Wall Refrigerant Piping Outdoor Unit Ceiling Grille Outdoor Unit 2

Style for Each and Every Room With an OmniCore Multi Room Heat Pump System, you have the flexibility to choose the perfect indoor heat pump for each room. Whether it’s a small capacity whisper quiet high wall for the bedroom, a compact floor console for the office or a discreet ducted model for the lounge, there is a style and capacity to fit any room – no matter the size or interior aesthetic. Individual Temperature Control for Each Room An OmniCore Multi Room System allows individual control of every heat pump in your home; whether you want to increase the temperature in the kids' bedrooms before bedtime, or turn off the living room heat pump as you head out for dinner. With individual heat pump control, you can adjust the temperature to suit your comfort levels and ensure a heat pump is only operating when needed; maximising energy savings. Keep Your Exterior Clutter-Free While a standard heat pump system requires a separate outdoor unit for every indoor unit inside the home, an OmniCore Multi Room Heat Pump System is specifically designed so you have the flexibility to connect multiple indoor units to just one OmniCore outdoor unit. With a range that provides sizing options from one to eight rooms, a total home heating and cooling solution with a clutter-free exterior is now possible. Future-Proof and Add Units as Your Family Grows With an OmniCore Multi Room System, there is no need to hurry and choose all the possible indoor units for your home at once. Indoor units do not have to be connected all at the same time when you first install the system. This means for example a four room system could be installed with only two indoor units connected to begin with; giving you the flexibility to add up to two more rooms in the future – all connected to the one OmniCore outdoor unit. Optional Ventilation If you’re looking to create the perfect indoor environment for your home using an OmniCore Multi Room System, it is worth considering your home’s ventilation requirements. Mitsubishi Electric offer a range of Whole Home Heat Recovery Ventilation Systems that ensure clean, fresh air is supplied throughout your home. See pages 4–5 for more information. Why Choose an OmniCore Multi Room System? 3

Ventilating your home is vital as it maintains air quality and reduces moisture, creating a healthier and more comfortable environment. The Mitsubishi Electric Lossnay System is a patented heat recovery ventilation solution that uses fresh outdoor air (not attic air) to ventilate your home. The system works by extracting stale air from inside your house and replacing it with allergen-reduced fresh air from outside. Ventilation and Airtight Building Design Creating a healthy living environment is important when renovating or building a new home – you will want the perfect indoor climate year-round. In addition to efficient heating and cooling, this should include the optimum amount of circulating fresh air. Current building regulations now demand homes to be built more airtight as they are subjected to higher insulation standards. The option of leaving doors or windows open to allow more fresh air to enter is often not the solution from an outdoor noise or security perspective. Ventilation, Condensation and Moisture Management The lack of natural ventilation due to airtight spaces can lead to the build-up of moisture-laden stale air within the home. This is the perfect breeding ground for mould that can trigger allergy or respiratory problems. Mould and dampness can compromise both building materials as well as furnishings inside the home. Common places for mould to grow include window sills, curtains and carpets. Maximise Heat Recovery Even From Warm Damp Areas* With its unique and highly efficient heat recovery ability, Mitsubishi Electric VL-type Lossnay Heat Recovery Systems maximise recovery of the available heat energy from outgoing stale air, as well as heat energy contained in moist air from damp areas such as bathrooms, toilets and kitchens. The Lossnay VL Series is available in either an in-ceiling or vertical solution, so there is an option to suit most New Zealand homes. Add Optional Lossnay Ventilation *Featured on the VL-type Heat Recovery Systems. 4

Features Improved Air Quality Brings in fresh outdoor air instead of polluted attic air. Removes odours, CO2 and other pollutants from your home. Creates a Healthier Home Filtered fresh air elevates air quality for allergy and asthma sufferers. Fresh Air Without Windows Open This improves the safety of your home and minimises outdoor noise. Energy Efficient Incoming fresh air is pre-warmed so your heating system isn’t required to work as hard to reach desired temperatures. This is highly energy efficient, and can help reduce heating bills. Retains Heat Lossnay’s unique Heat Recovery Technology collects up to 92% of the heat energy in outgoing air which is then used to pre-warm or cool the fresh air vented in. Assists Moisture and Condensation Control Lossnay effectively controls moisture in your home by directly removing stale air that causes condensation via the Lossnay Core. Balanced Pressure, No Draughts Lossnay brings in the optimum amount of fresh air without creating draughts and minimising indoor temperature fluctuations. Free Summer Cooling*† When Auto Mode is activated cooler fresh air is introduced and stale air is extracted, bypassing the Lossnay Core. This is ideal for cooling down a dwelling that may have overheated during the day, once the outside temperature has dropped in the evening. For details on Lossnay product solutions and Lossnay Advanced Wi-Fi Control, see page 32. How it Works Extracts stale air Supplies fresh air Lossnay heat recovery EXTRACTS STALE AIR Extracts stale air removing toxins and reducing humidity. SUPPLIES FRESH AIR Supplies fresh air increasing the oxygen levels in the home and assists with managing the build-up of moisture. HEAT RECOVERY Recovers up to 92% of the heat energy from the outgoing air to preheat the incoming air, saving you money. * Built in to the Vertical Lossnay and LGH-RVX model systems only. † In comparison to using a dedicated cooling device. The unit will continue to use a small amount of power to circulate the pre-cooled air. Make Heat Recovery Ventilation Visible – with Advanced Lossnay Wi-Fi Control Now you can see by how many degrees** Lossnay is pre-warming or cooling your home in real time, helping you save on your power bill because less additional heating is required to get a room up to the desired temperature. The app will also proactively remind you when it is time to clean your filters to maximise both cost efficient operation and health benefits. ** The outside ‘Fresh Air’ and the inside ‘Avg Temp’ air temperatures are measured by the built-in sensors that are centrally located in the main Lossnay Ventilation unit. Automatic Free Cooling Pre-warming 5

What Indoor Units Can I Connect to My OmniCore Multi Room Heat Pump System? All of the Mitsubishi Electric indoor units listed within this brochure are compatible with a Mitsubishi Electric OmniCore Multi Room outdoor unit. MSZ-AP42VG Produces 3.1kW when both running at the same time MSZ-AP50VG Produces 3.7kW when both running at the same time MSZ-AP42VG This unit is currently turned off MSZ-AP50VG Produces 5.8kW when only one is running Will I Still Get Full Rated Capacity When Using an OmniCore Multi Room System? OmniCore Multi Room outdoor units have different maximum capacities of heating kW and cooling kW. Depending on the indoor units chosen, the actual capacity of heating/cooling produced by the indoor unit may vary from the actual rated capacity. This is because the power of the OmniCore outdoor unit is distributed across all the connected indoor units that are running. For example, if you have an AP42 and an AP50 indoor unit connected to an MXZ-3F54VGD outdoor, when the two indoor units operate simultaneously in Heating Mode, the AP42 will produce up to 3.1kW, and the AP50 will produce 3.7kW of its rated heating capacity. When only one indoor unit is running, for example the AP50, you will receive up to an impressive 5.8kW of rated heating capacity from the AP50 alone. Choosing the Right Heat Pumps for Your Home Book a Free In-Home Consultation Once you have selected your preferences, we recommend you book a free in-home consultation with one of our qualified installers. Choosing the right heat pump system requires an assessment of the areas in your home that need to be heated; ensuring you get the best, most efficient system. A qualified installer will carry out accurate sizing calculations and expertly assess other factors involved in heat loss and gain. To book your free in-home consultation please visit www.mitsubishi-electric.co.nz/heatpump/installer for your nearest Mitsubishi Electric recommended heat pump installer. High Wall Mounted Floor Console Ceiling Mounted Ducted/Concealed 6

MXZ-2F52VF EXAMPLE Each indoor unit has a maximum class no greater than 50, and the total maximum class combination of all indoors is no greater than 75 (in this example totalling 75). For more OmniCore Multi Room examples visit www.mitsubishi-electric.co.nz/multiroom To help assist in your decision, all Mitsubishi Electric indoor units have a class rating; this is the numerical component of the model name. For example, the MSZ-AP25VG has a class rating of 25. Every OmniCore Multi Room outdoor unit has three parameters that determine the number and size of indoor units that can be connected to it: 1. The number of indoor units that can be connected (ranging from 1–8 indoor units dependent on outdoor unit). 2. The maximum individual indoor class rating that can be connected (ranging from 15–100). 3. The maximum total class rating of all units that can be connected (ranging from 75–202 dependent on unit). OUTDOOR UNIT CONNECTABLE INDOOR UNIT PARAMETERS Small to Medium Homes OmniCore Classic Multi Series MXZ-2F52VF 6.1kW Heating Connect 2 indoors Each indoor can be up to a Class 50 Maximum Class total of 75 for all indoor units MXZ-3F54VGD 7.0kW Heating Connect 2–3 indoors Each indoor can be up to a Class 50 Maximum Class total of 100 for all indoor units MXZ-4F71VGD 8.0kW Heating Connect 2–4 indoors Each indoor can be up to a Class 60 Maximum Class total of 125 for all indoor units MXZ-4F80VGD 8.8kW Heating Connect 1–4 indoors* Each indoor can be up to a Class 71 Maximum Class total of 145 for all indoor units This outdoor unit can only use 1x Class 71 indoor MXZ-5F100VGD 10.0kW Heating Connect 1–5 indoors* Each indoor can be up to a Class 71 Maximum Class total of 171 for all indoor units This outdoor unit can only use 1x PEAD-M71 MXZ-6F120VGD 13.2kW Heating Connect 1–6 indoors* Each indoor can be up to Class 80 Maximum Class total of 180 for all indoor units This outdoor unit can only use 1x PEAD-M71 Larger Homes and Light Commercial OmniCore Pro Multi Series PUMY-SP80VKMD-A 10.0kW Heating Connect 2–7 indoors Each indoor can be up to Class 100† Maximum Class total of 117 for all indoor units PUMY-SP112VKMD-A 14.0kW Heating Connect 2–8 indoors Each indoor can be up to Class 100 Maximum Class total of 162 for all indoor units PUMY-SP125VKMD-A 16.0kW Heating Connect 2–8 indoors Each indoor can be up to Class 100 Maximum Class total of 182 for all indoor units PUMY-SP140VKMD-A 16.5kW Heating Connect 2–8 indoors Each indoor can be up to Class 100 Maximum Class total of 202 for all indoor units How Many Indoor Units Can be Connected? MSZ-AP50VG (Class 50) High Wall Indoor Unit MXZ-2F52VF OmniCore Classic Multi Outdoor Unit MFXZ-KW25VG (Class 25) Floor Console Indoor Unit * At least two indoor units must be connected when using an indoor unit with capacity lower than 25 class. † To maximise use of available capacity, indoor units over Class 71 are not recommended to be connected to PUMY-SP80. 7

The OmniCore Classic Multi Series is the perfect total home solution, providing heating and cooling in up to six rooms. Features R32 Refrigerant The introduction of R32 in the MXZ Classic Multi Series has enabled an increased energy efficiency, with just one third of the global warming potential of R410A. Energy Saving with High COP Mitsubishi Electric Inverter Technology provides superior energy efficiency with high COPs (Coefficient of Performance). For example, a COP of over 4 means that for every 1kW of power input, you get over 4kW of heat energy output! MODEL COP MXZ-2F52VF 4.09 MXZ-3F54VGD 4.90 MXZ-4F71VGD 4.79 MXZ-4F80VGD 5.24 MXZ-5F100VGD 4.83 MXZ-6F120VGD 4.40 Fix Operation Mode It is possible to lock operation to ‘Heating’ or ‘Cooling’ Mode. This is convenient in places such as rental properties. Longer Piping Length Piping is extendable up to 25m per indoor unit* with no more than 15m in height (additional refrigerant charge may be required). Total install pipe length may extend up to 80m.† Guaranteed Heating Down to -15°C Not all heat pumps perform when they are needed most. Our OmniCore Classic Multi Series is guaranteed to effectively provide heating on those cold nights or mornings when you really need it. Controllers Refer to page 30 for the full list of available controls. Optional Ventilation If you’re looking to create the perfect indoor environment for your home using an OmniCore Multi Room System, it is worth considering your home’s ventilation requirements. Mitsubishi Electric offer a range of Whole Home Heat Recovery Ventilation Systems that ensure clean, fresh air is supplied throughout your home. OmniCore Classic Multi Series * MXZ-2F52 up to 20m. † MXZ-5F100 and MXZ-6F120. The Mitsubishi Electric OmniCore Classic Multi Series is the perfect solution for small to medium-sized homes. 8

The OmniCore Pro Multi Series also known as Mini-VRF, is a quiet, highly efficient and flexible heat pump system providing heating and cooling for up to eight rooms. Features Super Silent Mode – Cooling Only* Perfect for evenings and residential areas, the noise level of the OmniCore Pro Multi Series can be reduced by up to 10dBA, providing quiet operation when it is needed most. Guaranteed Heating Down to -20°C The OmniCore Pro Multi Series is able to provide heating when you need it most, right down to -20°C outdoor temperature. Simple and Discreet Design The single fan unit offers a low height profile and small footprint, keeping your outdoor space uncluttered. Energy Saving with High COP The OmniCore Pro Multi Series provides superior energy efficiency with high COPs (Coefficient of Performance). With COPs over 4, for every 1kW of power input, you get over 4kW of heat energy output! Branch Box The Mitsubishi Electric Branch Box is unique to the OmniCore Pro Multi Series. Simplifying installation, the Branch Box enables a more flexible and cost-effective approach. Central Control Compatible The new PUMY-SP Series are compatible with central controllers AE-200E, AE-50E, EW-50 and AT-50B, providing full centralised control! Optional Ventilation If you’re looking to create the perfect indoor environment for your home using an OmniCore Multi Room System, it is worth considering your home’s ventilation requirements. Mitsubishi Electric offer a range of Whole Home Heat Recovery Ventilation Systems that ensure clean, fresh air is supplied throughout your home. MODEL COP PUMY-SP80VKMD 4.41 PUMY-SP112VKMD 4.42 PUMY-SP125VKMD 4.10 PUMY-SP140VKMD 4.10 OmniCore Pro Multi Series The Mitsubishi Electric OmniCore Pro Multi Series has been designed specifically for larger homes, offices and other light commercial applications. *PAC-SC36NA-E is required to activate Super Silent Mode. 9

EcoCore AP Series EcoCore AP Mini Designer EF Series Black Diamond LN Series RapidHeat KW Series High Wall High Wall High Wall High Wall Floor ​ Console Outdoor Units Page 12 Page 14 Page 15 Page 16 Page 18 OmniCore Classic Multi Series MXZ-2F52VF Connect 2 indoor units Up to Class 50 (total 75)* Heating Capacity: 6.1 kW Cooling Capacity: 5.2 kW AP25 AP35 AP42 AP50 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 MFXZ-KW25 MFXZ-KW35 MXZ-3F54VGD Connect 2–3 indoor units Up to Class 50 (total 100)* Heating Capacity: 7.0 kW Cooling Capacity: 5.4 kW AP25 AP35 AP42 AP50 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 MXZ-4F71VGD Connect 2–4 indoor units Up to Class 60 (total 125)* Heating Capacity: 8.0 kW Cooling Capacity: 7.1 kW AP25 AP35 AP42 AP50 AP60 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 MXZ-4F80VGD Connect 1–4 indoor units† Up to Class 71 (total 145)*1 Heating Capacity: 8.8 kW Cooling Capacity: 8.0 kW AP25 AP35 AP42 AP50 AP60 AP71 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 MXZ-5F100VGD Connect 1–5 indoor units† Up to Class 71 (total 171)*2 Heating Capacity: 10.0 kW Cooling Capacity: 10.0 kW AP25 AP35 AP42 AP50 AP60 AP71 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 MXZ-6F120VGD Connect 1–6 indoor units† Up to Class 80 (total 180)*2 Heating Capacity: 13.2 kW Cooling Capacity: 12.0 kW AP25 AP35 AP42 AP50 AP60 AP71 AP80 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 OmniCore Pro Multi Series PUMY-SP80VKMD Connect 2–7 indoor units Up to Class 100 (total 117)* Heating Capacity: 10.0kW Cooling Capacity: 9.0 kW AP25 AP35 AP42 AP50 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 PUMY-SP112VKMD Connect 2–8 indoor units Up to Class 100 (total 162)* Heating Capacity: 14.0 kW Cooling Capacity: 12.5 kW AP25 AP35 AP42 AP50 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 PUMY-SP125VKMD Connect 2–8 indoor units Up to Class 100 (total 182)* Heating Capacity: 16.0 kW Cooling Capacity: 14.0 kW AP25 AP35 AP42 AP50 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 PUMY-SP140VKMD Connect 2–8 indoor units Up to Class 100 (total 202)* Heating Capacity: 16.5 kW Cooling Capacity: 15.5 kW AP25 AP35 AP42 AP50 AP15 AP20 EF22 EF25 EF35 EF42 EF50 LN25 LN35 LN50 MFXZ-KW25 MFXZ-KW35 MFXZ-KW50 To be used as a guide only. Please view the outdoor unit's capacity charts on www.mitsubishi-electric.co.nz/multiroom for possible combination connections. 1 Note: The MXZ-4F80 can only use 1x class 71 indoor. 2 Note: The MXZ-5F100 and MXZ-6F120 can only use 1x PEAD-M71. *Total maximum capacity connectable. † At least two indoor units must be connected when using indoor unit with capacity lower than 25 class. Compatibility Chart 10

PFFY Series SEZ Series PEFY-VMA PEFY-VMX PEAD Series MLZ Series SLZ Series PLA Series PCA Series Concealed Floor Console Ceiling Concealed Ducted Ducted Ducted One-Way Ceiling Cassette Compact Ceiling Cassette Ceiling Cassette Under- Ceiling Page 20 Page 21 Page 22 Page 23 Page 24 Page 25 Page 26 Page 27 Page 28 SEZ-M35 MLZ-KP25 MLZ-KP35 SLZ-M25 SLZ-M35 SEZ-M35 SEZ-M50 PEAD-M50 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 SEZ-M35 SEZ-M50 SEZ-M60 PEAD-M50 PEAD-M60 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 SEZ-M35 SEZ-M50 SEZ-M60 SEZ-M71*1 PEAD-M50 PEAD-M60 PEAD-M71*1 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 SEZ-M35 SEZ-M50 SEZ-M60 SEZ-M71 PEAD-M50 PEAD-M60 PEAD-M71*2 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 SEZ-M35 SEZ-M50 SEZ-M60 SEZ-M71 PEAD-M50 PEAD-M60 PEAD-M71*2 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 PFFY-P20 PFFY-P25 PFFY-P32 PFFY-P40 PFFY-P50 SEZ-M35 SEZ-M50 SEZ-M60 SEZ-M71 PEFY-P20VMA PEFY-P25VMA PEFY-P32VMA PEFY-P40VMA PEFY-P50VMA PEFY-P20VMX PEFY-P25VMX PEFY-P32VMX PEFY-P40VMX PEFY-P50VMX PEFY-P63VMX PEAD-M50 PEAD-M60 PEAD-M71 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 PLA-M71 PCA-M50 PCA-M60 PCA-M71 PFFY-P20 PFFY-P25 PFFY-P32 PFFY-P40 PFFY-P50 SEZ-M35 SEZ-M50 SEZ-M60 SEZ-M71 PEFY-P20VMA PEFY-P25VMA PEFY-P32VMA PEFY-P40VMA PEFY-P50VMA PEFY-P20VMX PEFY-P25VMX PEFY-P32VMX PEFY-P40VMX PEFY-P50VMX PEFY-P63VMX PEAD-M50 PEAD-M60 PEAD-M71 PEAD-M100 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 PLA-M71 PLA-M100 PCA-M50 PCA-M60 PCA-M71 PCA-M100 PFFY-P20 PFFY-P25 PFFY-P32 PFFY-P40 PFFY-P50 SEZ-M35 SEZ-M50 SEZ-M60 SEZ-M71 PEFY-P20VMA PEFY-P25VMA PEFY-P32VMA PEFY-P40VMA PEFY-P50VMA PEFY-P20VMX PEFY-P25VMX PEFY-P32VMX PEFY-P40VMX PEFY-P50VMX PEFY-P63VMX PEAD-M50 PEAD-M60 PEAD-M71 PEAD-M100 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 PLA-M71 PLA-M100 PCA-M50 PCA-M60 PCA-M71 PCA-M100 PFFY-P20 PFFY-P25 PFFY-P32 PFFY-P40 PFFY-P50 SEZ-M35 SEZ-M50 SEZ-M60 SEZ-M71 PEFY-P20VMA PEFY-P25VMA PEFY-P32VMA PEFY-P40VMA PEFY-P50VMA PEFY-P20VMX PEFY-P25VMX PEFY-P32VMX PEFY-P40VMX PEFY-P50VMX PEFY-P63VMX PEAD-M50 PEAD-M60 PEAD-M71 PEAD-M100 MLZ-KP25 MLZ-KP35 MLZ-KP50 SLZ-M25 SLZ-M35 SLZ-M50 PLA-M71 PLA-M100 PCA-M50 PCA-M60 PCA-M71 PCA-M100 11

12 High Wall EcoCore Series – AP Classic and AP Plus Dimensions (WxDxH): 798 x 219 x 299mm MSZ-AP25VG(K)D Heating Capacity: 3.2 kW | Cooling Capacity: 2.5 kW MSZ-AP35VG(K)D Heating Capacity: 3.7 kW | Cooling Capacity: 3.5 kW MSZ-AP42VG(K)D Heating Capacity: 5.4 kW | Cooling Capacity: 4.2 kW MSZ-AP50VG(K)D Heating Capacity: 6.0 kW | Cooling Capacity: 5.0 kW Dimensions (WxDxH): 1100 x 257 x 325mm MSZ-AP60VG(K)D Heating Capacity: 6.8 kW | Cooling Capacity: 6.0 kW MSZ-AP71VG(K)D Heating Capacity: 8.0 kW | Cooling Capacity: 7.1 kW MSZ-AP80VG(K)D Heating Capacity: 9.0 kW | Cooling Capacity: 7.8 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. The AP Series High Wall Heat Pumps set a new standard in super energy efficient heating. And starting at just 18dBA*, it's NZ's quietest – ideal for living rooms and bedrooms! New Zealand's Quietest Heat Pump!* Starting at an incredibly quiet 18dBA on its lowest fan speed, the AP25 indoor unit is New Zealand’s quietest high wall heat pump ever. It is ideal where quietness matters most, in bedrooms even on the coldest of winter nights. Furthermore, the addition of Night Mode means the outdoor operating noise level drops by a further 3dBA for the perfect night’s sleep. The Secret to Quietness By making the heat exchanger 32% thinner† and designing the fan coil to be 22% larger† in comparison to previous models, pressure loss across the heat exchanger is minimised and air can now be moved across a larger fan surface. Add to this a new aerodynamically designed fan coil, and a new level of quietness has been achieved! Never Return to a Cold Home Again With Wi-Fi Control With Wi-Fi Control you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you're in a different country, with Wi-Fi Control you'll always arrive home to total comfort. Wi-Fi Control is built-in to the AP Plus Series and available as an optional upgrade with the AP Classic Series. And because our Wi-Fi Control is now also Amazon Alexa and Google Home enabled, you can take your comfort to the next level and enjoy hands-free heat pump control. You can find out more about Wi-Fi and Voice Control on page 30. 18dBA AP25* * AP25 indoor sound level on lowest fan setting in Heating Mode. † Compared to MSZ-GL Series. AP Classic AP Plus

AP Series Features 18dBA† NZ's Quietest Heat Pump Econo Cool Washable Air Purifying Filter Dual Barrier Coating 7-Day Programmable Controller Auto Vane Control Horizontal Airflow Wide and Long Air Flow* Night Mode i-Save Mode * AP60/71/80 only † AP25 indoor sound level on lowest fan setting in Heating Mode. Dual Barrier Coating Maximises Efficient Performance The patented and world’s first Dual Barrier Coating from Mitsubishi Electric prevents dust and dirt from accumulating on the inner surface of the indoor unit; keeping your heat pump clean year-round. Keeping key internal components like the heat exchanger, fan and internal duct clean is important for both home comfort and efficiency. Not only does dust and dirt build-up typically create unpleasant odours, it also forces a heat pump to work harder, which can result in significantly impaired energy efficiency. Dual Barrier Coating prevents dust and oil build-up on the interior of the heat pump for the ultimate in peace of mind, ease and comfort. Horizontal Airflow The AP Series eliminates uncomfortable draughts with Horizontal Airflow in Cooling Mode, by spreading airflow evenly across the ceiling. Optional Plasma Quad Connect for Cleaner, Healthier Air Designed to integrate with your existing EcoCore AP Series Heat Pump, this high-performance two-stage advanced air filtration module, cleans and minimises dust and other allergens for better indoor air quality, all year round. Wide and Long Airflow* The Wide Airflow Mode enables airflow direction to be adjusted from left to right, ideal for open plan environments – ensuring every corner of the room is comfortable. The Long Airflow Mode extends airflow distance. These modes are simply activated at the touch of a button on your remote controller. Washable Air Purifying Filter The AP Series is equipped with an Air Purifying Filter. This washable filter traps particles such as dust, pollen and other airborne contaminants, generating stable antibacterial and deodorising effects. The size of the three-dimensional surface has been increased from previous models, enlarging the filter capture area. These features give the Air Purifying Filter better dust collection performance than conventional filters. Close-up of Air Purifying Filter Comparison of dirt on heat exchanger, fan and air duct (Factory simulated in-house comparison) No Dual Barrier Coating (Image after 10 years) Dual Barrier Coating used Heat Exchanger Fan Air Duct Advanced Air Filtration Optional 13

14 The AP Mini High Wall Heat Pump brings leading edge technology and features to New Zealand's most compact high wall indoor unit. The ultimate solution for bedrooms or small rooms where space is at a premium. Pint-sized but big on performance, the AP Mini is packed with features that maximise energy efficiency. New Zealand's Most Compact High Wall Indoor Unit Specifically designed where space is at a premium the 250mm by 760mm wide footprint makes it ideal for positioning above doorways in bedrooms as well as in home offices. Now smaller spaces no longer need to miss out on year-round comfort. With a 16.4% size reduction in height and 5% reduction in width when compared to the bigger AP 25-50 models, they can even be installed in very tight places that would traditionally not have been possible, such as above doorways. Dual Barrier Coating Maximises Efficient Performance The patented and world’s first Dual Barrier Coating from Mitsubishi Electric prevents dust and dirt from accumulating on the inner surface of the indoor unit. By keeping your heat pump clean year-round you can rest assured your heat pump will always perform at its best. EcoCore Series – AP Mini Dimensions (WxDxH): 760 x 178 x 250mm MSZ-AP15VGD Heating Capacity: 1.7 kW | Cooling Capacity: 1.5 kW MSZ-AP20VGD Heating Capacity: 2.5 kW | Cooling Capacity: 2.0 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. AP Mini Features Dual Barrier Coating 7-Day Programmable Controller Auto Vane Control Horizontal Airflow Night Mode Econo Cool Optional Plasma Quad Connect Air Filtration Accessory Washable Air Purifying Filter i-Save Mode High Wall * Wi-Fi adapter must be mounted externally. † Compared to the MSZ-AP25-50 models. AP MINI SIZE COMPARISON AP25/35/42/50 AP15/20 Mini †

15 The Designer EF Series features exceptional energy efficiency and built-in Wi-Fi Control. Elegant and slimline in design, these heat pumps are available in a choice of colours so you can truly reflect your interior design style. Colour – Now There is a Choice One of the most rewarding aspects of interior design is being able to inject your own design personality through colour selection and accessorising. With three colours to choose from, the Designer EF Series allows you to make a real style statement with your heat pump. Mix or match our Pure White, Matte Silver and Rich Black Diamond colour options to blend in or stand out – it’s up to you! Built-In Wi-Fi Control Never Return to a Cold Home Again With Mitsubishi Electric Wi-Fi Heat Pump Control you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you're in a different country, with Wi-Fi Control you'll always arrive home to total comfort regardless of what New Zealand's unpredictable weather is doing outside! Optional Plasma Quad Connect for Cleaner, Healthier Air Designed to integrate with your existing Designer EF Series Heat Pump, this highperformance two-stage advanced air filtration module, cleans and minimises dust and other allergens for better indoor air quality, all year round. EcoCore Designer EF Series Dimensions (WxDxH): 885 x 195 x 299mm MSZ-EF22VGKW/B/S Heating Capacity: 3.0 kW | Cooling Capacity: 2.2 kW MSZ-EF25VGKW/B/S Heating Capacity: 3.2 kW | Cooling Capacity: 2.5 kW MSZ-EF35VGKW/B/S Heating Capacity: 4.0 kW | Cooling Capacity: 3.5 kW MSZ-EF42VGKW/B/S Heating Capacity: 5.4 kW | Cooling Capacity: 4.2 kW MSZ-EF50VGKW/B/S Heating Capacity: 5.8 kW | Cooling Capacity: 5.0 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. *EF25 indoor sound level on lowest fan speed in Cooling Mode. Designer EF Series Features Whisper Quiet Operation from 19dBA* Auto Change Over Function 1 Watt Low Standby Power Red Dot Design Award Winner Built-in Wi-Fi Control EA Electrostatic Anti-Allergy Enzyme Filter (Optional) AA Anti-Allergy Enzyme Filter LED Backlit and Coloured 7-Day Programmable Controller High Wall Advanced Air Filtration Optional

16 Black Diamond LN Series The Black Diamond LN Series sets the new standard in personalised comfort and style. Available in three unique reflective colours, the range is packed with advanced features including Plasma Quad Plus Filtration, the 3D i-See Sensor for customised heating or cooling, and Dual Barrier Coating to maximise year-round energy efficient performance. Reflect Your Design Personality Featuring a striking flat panel design, the Black Diamond LN Series is available in three unique reflective colour finishes – White Diamond, Red Diamond and Black Diamond, that change depending on the light in the room. 3D i-See Sensor The 3D i-See Sensor detects the presence and position of people in the room using thermal heat recognition, adjusting the temperature and airflow pattern for optimal comfort. This helps the Black Diamond LN Series do more than simply save energy, it also enables a new level of truly personalised comfort to be achieved. Thermal Scan Technology The 3D i-See Sensor continually takes a thermal scan of the room, dividing it into 752 three-dimensional zones and measuring the temperature in each zone to detect exactly where people are in a room. Independently Controlled Dual Split Vane Airflow Intuitively Adjusts the Airflow Direction to Where It’s Needed The 3D i-See Sensor works in conjunction with the Dual Split Vanes to provide heating or cooling to where it is needed most. As a result, it can save energy by not heating or cooling areas that don’t require it. Whether you prefer direct, indirect or evenly distributed airflow, the 3D i-See Sensor and Dual Split Vanes provide the ultimate in customisable airflow. Dimensions (WxDxH): 890 x 233 x 307mm MSZ-LN25VG2V/B/R Heating Capacity: 3.2 kW | Cooling Capacity: 2.5 kW MSZ-LN35VG2V/B/R Heating Capacity: 4.0 kW | Cooling Capacity: 3.5 kW MSZ-LN50VG2V/B/R Heating Capacity: 6.0 kW | Cooling Capacity: 5.0 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. You always feel warm and comfortable as the direct heat follows you as you move around the room. 752 three-dimensional zones 8 x 94 areas High Wall

You'll Never Feel Cold The 3D i-See Sensor can recognise movement of an individual in a room and subsequently direct the airflow with the Dual Split Vanes; so they continue feeling warm no matter where they have moved to in the room. Dual Barrier Coating Maximises Efficient Performance The patented and world’s first Dual Barrier Coating from Mitsubishi Electric prevents dust and dirt from accumulating on the inner surface of the indoor unit; keeping your heat pump clean year-round for the ultimate in peace of mind, ease and comfort. Keeping key internal components like the heat exchanger, fan and internal duct clean is important for both home comfort and efficiency. Not only does dust and dirt build-up typically create unpleasant odours, it also forces a heat pump to work harder, which can result in significantly impaired energy efficiency. † MSZ-LN25/35 indoor sound level on lowest fan speed. * PQC Electrode Collection Plate, Test Chamber Lab – Test No. 20KB070569, Microbial Testing Laboratory Kobe Testing Center Japan Textile Products Quality and Technology Center. Black Diamond LN Series Features Whisper Quiet Operation from 19dBA† Dual Barrier Coating i-Save Mode 3D i-See Sensor Plasma Quad Plus Filtration System Econo Cool Dual Split Vane Technology LED Backlit 7-Day Programmable Controller 10°C Heating Mode Night Mode Auto Vane Control Built-In Wi-Fi Control Comparison of dirt on heat exchanger, fan and air duct. (Factory simulated in-house comparison.) No Dual Barrier Coating (after 10 years) With Dual Barrier Coating Heat Exchanger Fan Air Duct Advanced Plasma Quad Plus Filtration The advanced Plasma Quad Plus Filtration System, featuring high-performance two stage plasma technology, filters the air to clean away viruses such as Covid-19* as well as smells, dust, moulds and other common household allergens. Two Stage Plasma Filter The Plasma Quad Plus Filter works like an electrical curtain, using an electrical discharge to catch and neutralise even microscopically small particles in the air. In fact, it can even capture PM2.5 particles (which are up to 20 times smaller than the width of a human hair!). Built-In Wi-Fi Control Never Return to a Cold Home Again Now you can pre-heat or cool a room no matter where you are. On the way home, running late, or in a different country, with Wi-Fi Control you'll always arrive home to total comfort. Quiet Operation Mitsubishi Electric Heat Pumps are designed to be very, very quiet. Constant development to reduce sound levels has resulted in our Black Diamond LN Series High Wall indoor units starting at an amazingly quiet 19dBA†, making them ideal where it matters most – in living rooms and bedrooms. The Black Diamond LN Series also features Night Mode which disables beeping sounds and dims the indicator light. Only one person feels direct heat. Both people feel direct heat and are both comfortable. Bacteria Airborne Contaminants Moulds Allergens Micro Particles Dust 17

18 RapidHeat KW Series The RapidHeat KW Floor Console features a contemporary slimline design and dramatically reduced depth. RapidHeat KW Floor Consoles are the perfect solution for unobtrusive heating at floor level. Advanced sensors with Intuitive Control Logic Technology offer unparalleled low temperature heating performance in the shortest amount of time, all while maintaining maximum energy efficiency. RapidHeat Technology INDUSTRY FIRST Advanced sensors coupled with Intuitive Control Logic mean optimal running temperatures are reached in the shortest amount of time possible with maximum energy efficiency. Automatically activated at start up in low temperature conditions when Two-Way Airflow is selected, warm air is blown in a downward direction first before the air is returned back into the indoor unit where it is reheated a second time. As a result, a room can now be heated up to twice as fast compared to our previous model.* Multi Vane Flow – Even Heat Distribution INDUSTRY FIRST The Multi Vane Flow function blows warm air in both an upward and downward direction providing fast, even and effective heating whilst also reducing draughts. This is achieved via three uniquely shaped vanes that are designed for better airflow control and also provide the freedom to be customised to your preference. Dimensions (WxDxH): 750 x 215 x 600mm MFXZ-KW25VG Heating Capacity: 3.4 kW | Cooling Capacity: 2.5 kW MFXZ-KW35VG Heating Capacity: 4.3 kW | Cooling Capacity: 3.5 kW MFXZ-KW50VG Heating Capacity: 5.8 kW | Cooling Capacity: 5.0 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. Floor Console * MFZ-KA Series.

Sleek, Sophisticated Design Mitsubishi Electric RapidHeat KW Floor Consoles feature a contemporary design that can be recessed into your wall to dramatically reduce the depth of the indoor unit from 215mm to 145mm – a decrease of 33%. With the addition of a removable base, it is the perfect solution offering compact, unobtrusive heating for new buildings, renovation projects and fireplace replacements. Cleaner, Healthier Air RapidHeat KW Floor Consoles make use of two types of filtration to provide cleaner, healthier air. The Air Purifying Filter generates stable antibacterial and deodorising effects, whilst the Electrostatic Anti-Allergy Enzyme Filter uses enzyme catalysts to filter allergens and remove harmful bacteria. 7-Day Programmable Controller The RapidHeat KW Floor Consoles feature a built-in weekly timer, allowing you to program up to four time and temperature settings for each day of the week. You can now return to comfort without having to manually adjust the temperature. Perfect for anyone with a busy lifestyle, the 7-Day Controller is a great way to regulate your energy usage without compromising on comfort. Optional Wi-Fi Control Never Return to a Cold Home Again With Mitsubishi Electric Wi-Fi Heat Pump Control you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you're in a different country, with Wi-Fi Control you'll always arrive home to total comfort regardless of what New Zealand's unpredictable weather is doing outside! Recessable - reduces depth by 33% (70mm) Removable base Sleek, simple design Multi Vane Flow Recessed with base removed (145mm) RapidHeat KW Series Features RapidHeat Technology Sleek Contemporary Design 7-Day Programmable Controller Multi Vane Flow Air Purifying Filter Optional Wi-Fi Control AA Anti-Allergy Enzyme Filter Recessable Design Auto Vane Control 19

20 PFFY Floor Console Series (OmniCore Pro Multi Series only) Concealed Floor Console A compact, concealed floor console providing simple, effective air conditioning in perimeter zones. Compact Unit for Easy Perimeter Air Conditioning The body is concealed in the perimeter cover for a cohesive fit with the interior. The compact body depth of 220mm (8-11/16") can easily be installed in a perimeter zone. Maximum External Static Pressure 60Pa Additional external static pressure capacity provides flexibility for duct extension, branching, and air outlet configuration. The ability to add ducting allows for a wide range of installation possibilities. Concealed Type Design The perfect solution to preserve architectural style in homes or offices with no ceiling space. The PFFY Series can be concealed in the perimeter skirting wall or other wall space voids to preserve the appearance of the building's interior. Electronic Dry Function Provides optimum dehumidification depending on indoor temperature to prevent over-cooling. Dimensions (WxDxH): PFFY-P20-25: 886 x 220 x 639mm PFFY-P32-40: 1006 x 220 x 639mm PFFY-P50: 1246 x 220 x 639mm PFFY-P20VCM Heating Capacity: 2.5 kW | Cooling Capacity: 2.2 kW PFFY-P25VCM Heating Capacity: 3.2 kW | Cooling Capacity: 2.8 kW PFFY-P32VCM Heating Capacity: 4.0 kW | Cooling Capacity: 3.6 kW PFFY-P40VCM Heating Capacity: 5.0 kW | Cooling Capacity: 4.5 kW PFFY-P50VCM Heating Capacity: 6.3 kW | Cooling Capacity: 5.6 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. PFFY Series Features Electronic Dry Function 60Pa for Duct Extension Compact Design Washable Air Cleaning Filter Optional Wi-Fi Control

21 Compact, whisper quiet and highly efficient, our ceiling concealed SEZ Series fit easily and discreetly into rooms with lowered ceilings. Optional fresh air intake provides all-round refreshing comfort. Compact Design Ceiling concealed and a slim 200mm in height, the SEZ Series is ideal for tight installation spaces. Quiet Comfort The SEZ Series offers whisper quiet operation, starting at a hushed 23dBA.* Air Cleaning Filter This built-in filter removes dust and other irritating particles, keeping the air clean at all times. Maintenance is as simple as vacuuming. Easy Installation The SEZ Series lightweight design and low unit height makes for an easier and more convenient installation. SEZ Ceiling Concealed Series Dimensions (WxDxH): SEZ-M35-50DA: 990 x 700 x 200mm SEZ-M60-71DA: 1190 x 700 x 200mm SEZ-M35DA Heating Capacity: 4.0 kW | Cooling Capacity: 3.5 kW SEZ-M50DA Heating Capacity: 6.0 kW | Cooling Capacity: 5.0 kW SEZ-M60DA Heating Capacity: 7.0 kW | Cooling Capacity: 6.0 kW SEZ-M71DA Heating Capacity: 8.0 kW | Cooling Capacity: 7.1 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. *SEZ-M35DA indoor sound level on low fan speed. Ceiling Concealed SEZ Series Features Whisper Quiet Operation Lossnay Interlock Easy Installation Compact Design Low Temperature Performance Air Cleaning Filter

22 PEFY VMA Ducted Series (OmniCore Pro Multi Series only) The PEFY VMA Series offers a wide range of external static pressure and a low profile design that provides flexibility for narrow ceiling spaces. Compact Design Slim design with a height of no more than 250mm enables installation in ceilings with a small cavity. Maximum external static pressure of 150Pa Five-stage external static pressure settings provide flexibility for duct extension, branching and air outlet configuration and are adjustable to meet different application conditions. Settings range to a maximum of 150Pa. External Static Pressure Setting Series 20 25 32 40 50 PEFY-P VMA-E 35/50/70/100/150 Pa Air Inlet Direction Can Easily be Changed By only switching the closing board and air filter, the inlet layout can be altered from the rear inlet. (At the time of factory shipment: rear inlet) Built-In Drain Pump The PEFY-P VMA includes a built-in drain pump. Dimensions (WxDxH): PEFY-P20-32: 700 x 732 x 250mm PEFY-P40-50: 900 x 732 x 250mm PEFY-P20VMA-E Heating Capacity: 2.5 kW | Cooling Capacity: 2.2 kW PEFY-P25VMA-E Heating Capacity: 3.2kW | Cooling Capacity: 2.8 kW PEFY-P32VMA-E Heating Capacity: 4.0kW | Cooling Capacity: 3.6 kW PEFY-P40VMA-E Heating Capacity: 5.0kW | Cooling Capacity: 4.5 kW PEFY-P50VMA-E Heating Capacity: 6.3kW | Cooling Capacity: 5.6 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. Ducted Drain pump ensures up to 700 mm of lift. PEFY VMA Series Features Whisper Quiet Operation Wide Selection of Fan Speeds and Static Pressure Air Cleaning Filter Compact Design Easy Installation Optional Wi-Fi Control

23 PEFY VMX Ducted Series (OmniCore Pro Multi Series only) With a compact depth design and multiple air inlet positions, the PEFY VMX Series offers the ultimate in flexible installation. Compact Design The V-shaped design of the heat exchanger has allowed us to reduce the depth to just 450mm*, while the thin body height of just 200mm allows for installation in tight spaces such as above built-in wardrobes. Flexible Air Inlet Positions The compact PEFY VMX Series allows flexible installation options with three easily changeable air inlet positions. Changeable Static Pressures The range features the added flexibility of a selection of changeable static pressures. Series 20 25 32 40 50 63 PEFY-P VMX 4/15/35 Pa 4/15/35/45 Pa Dimensions (WxDxH): PEFY-P20-40: 698 x 450* x 200mm PEFY-P50: 948 x 450* x 200mm PEFY-P63: 1148 x 450* x 200mm PEFY-P20VMX-E Heating Capacity: 2.5 kW | Cooling Capacity: 2.2 kW PEFY-P25VMX-E Heating Capacity: 3.2kW | Cooling Capacity: 2.8 kW PEFY-P32VMX-E Heating Capacity: 4.0kW | Cooling Capacity: 3.6 kW PEFY-P40VMX-E Heating Capacity: 5.0kW | Cooling Capacity: 4.5 kW PEFY-P50VMX-E Heating Capacity: 6.3kW | Cooling Capacity: 5.6kW PEFY-P63VMX-E Heating Capacity: 8.0kW | Cooling Capacity: 7.1kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. PEFY VMX Series Features Whisper Quiet Operation Wide Selection of Fan Speeds and Static Pressure Air Cleaning Filter Compact Design Easy Installation Optional Wi-Fi Control Requires the same amount of installation space as the bottom-inlet models, but quieter. Low sound pressure level, suitable for installation where quietness is required. Requires less rear clearance space, allowing for installation in a tight space. Rear Inlet Top & Rear Inlet Bottom Inlet Wall Ceiling Wall Ceiling Wall Ceiling Ducted *Duct flange and filter are excluded.

24 The unobtrusive PEAD Ducted Whole Home System is specifically designed for installations where ceiling space is minimal. The system is super energy efficient and whisper quiet. With only its grilles visible, it is the perfect hidden comfort solution for heating or cooling multiple rooms at the same time. High Energy Saving Efficiency The PEAD Series achieves enhanced energy savings through adopting a highly efficient DC fan motor, contributing to an impressive reduction in electricity costs. Ideal Airflow The flexible duct design and variable-pressure of our ducted systems increase variation in airflow options, ensuring the system operates in a way that best suits virtually all room layouts. Wide Selection of Fan Speeds and External Static Pressure With a wide range of adjustable static pressures and fan speeds, these units are applicable to a wide range of building types and applications. Increase Savings by Combining Lossnay Ventilation Further increase energy savings while ventilating your home through the combination of a PEAD Ducted System interlocked with Mitsubishi Electric Lossnay. Both systems work in unison to intuitively remove stale air and control moisture whilst simultaneously recovering energy to provide your home with fresh, clean comfort. Recovered energy from outgoing stale air is used to pre-heat or pre-cool incoming fresh air. The net effect; an overall reduction in additional heating or cooling required. PEAD Ducted Series Dimensions (WxDxH): PEAD-M50: 900 x 732 x 250mm PEAD-M60: 1100 x 732 x 250mm PEAD-M71: 1100 x 732 x 250mm PEAD-M100: 1400 x 732 x 250mm PEAD-M50JAA Heating Capacity: 6.0 kW | Cooling Capacity: 5.0 kW PEAD-M60JAA Heating Capacity: 7.0 kW | Cooling Capacity: 6.0 kW PEAD-M71JAA Heating Capacity: 8.0 kW | Cooling Capacity: 7.1 kW PEAD-M100JAA Heating Capacity: 11.2 kW | Cooling Capacity: 10.0 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. Lossnay Interlock Ducted PEAD Series Features Whisper Quiet Operation Wide Selection of Fan Speeds and Static Pressure Air Cleaning Filter Compact Design Easy Installation Lossnay Interlock

25 The SlimFit MLZ Series with its streamlined design, airflow control features, and quiet operation from just 26dBA*, is ideal for small installation spaces where one-way air distribution is needed. Sleek, Slimline Design At just 185mm in height, the SlimFit MLZ Series is the perfect solution for low ceiling cavities, whilst the flat, pure white finish provides a sleek and discreet installation. Dual Level Airflow Selection The SlimFit MLZ Series is ideal for those with standard or high ceilings. With the ability to adjust airflow according to ceiling height and direction, uncomfortable draughts are a thing of the past. Auto Vane Control For the ultimate in airflow control, the SlimFit MLZ outlet vanes can be moved left, right, up and down using the remote controller; for airflow exactly where you want it. Quiet Operation Starting from just 26dBA*, the SlimFit MLZ Series offers unobtrusive, quiet comfort. No other one-way cassette is quieter! SlimFit MLZ Cassette Series Unit Dimensions (WxDxH): 1102 x 360 x 185mm Panel Dimensions (WxDxH): 1200 x 424 x 24mm MLZ-KP25VF Heating Capacity: 3.2 kW | Cooling Capacity: 2.5 kW MLZ-KP35VF Heating Capacity: 4.1 kW | Cooling Capacity: 3.5 kW MLZ-KP50VF Heating Capacity: 6.0 kW | Cooling Capacity: 5.0 kW Please note that the capacities may vary depending on the indoor/outdoor unit combination. Capacity Class 25 35 50 Standard 2.4m 2.4m 2.4m High Ceiling 2.7m 2.7m 2.7m Up and Down Left and Right Only available when Econo Cool is set. Up and Down Left and Right Only available when Econo Cool is set. One-Way Ceiling Cassette SlimFit MLZ Series Features Anti-Allergy Enzyme Filter Optional Horizontal Airflow High Ceiling Mode Air Cleaning Filter Auto Vane Easy Installation * MLZ-KP25 indoor sound level on lowest fan setting in Heating Mode.
