Highly Efficient Ducted Heating, Cooling and Ventilation Central Heating and Ventilation Quiet, Unobtrusive Year-Round Comfort for Your Whole Home
2 Experience Year-Round Comfort With a Whole Home Ducted Heat Pump System A Mitsubishi Electric Ducted Heat Pump System is designed to provide whole home central heating or cooling at a constant temperature throughout the house. Ideal for installing in new builds or retrofitted into existing homes, it is a costeffective and energy efficient solution for year-round comfort. Mitsubishi Electric Ducted Systems are whisper quiet, and with only its grilles visible, it is the perfect unobtrusive solution for whole home heating or cooling at the same time. Hidden From View Installed in the ceiling with only subtle grilles visible, a ducted system lets your interior design style take centre stage. Not only does a ducted system provide a whole home heating or cooling solution, it offers a sleek installation for the design-conscious. Grille Options to Compliment Your Interior Design Mitsubishi Electric Ducted Heat Pump Systems allow for a wide range of grille options to best suit your installation needs. From ceiling and wall installations, to underfloor grille options, talk to your installer about what’s right for you. Easy to Use 7-Day Wall Controller to Maximise Energy Efficiency This attractive full dot liquid crystal display incorporates a large backlit screen and simple menus for easy operation. You can set up to eight temperature and airflow patterns per day for seven days, maximising energy efficient operation – saving you both time and money. Optional Wi-Fi Control – Never Return to a Cold Home Again Pre-heat or cool the whole home no matter where you are. On the way home, running late, coming home early, or even when you’re in a different country, with optional Wi-Fi Control you’ll always arrive home to total comfort. Optional Zone Control Program and control up to 4 or up to 8 individual zones, providing heating or cooling only to the rooms that require it. Built-in sensor functions monitor room temperature, brightness and occupancy to maximise energy efficient use of the whole system throughout the home or just those rooms where it’s needed most. Note: All images are for illustrative purposes only.
3 Optional Wi-Fi Interlock for Total Home Control Seamlessly combine your Mitsubishi Electric Ducted Heat Pump and Lossnay Heat Recovery Ventilation System through your Wi-Fi Control App for the ultimate visibility and control. Because your Ducted Heat Pump needs to be in fan, heating or cooling mode for the connected Lossnay system to operate, you can now choose from two innovative modes to customise your climate control setup. Use the “Power Interlock” mode, to enjoy set and forget convenience. In this mode, both systems will always automatically activate together no matter which system you initially turn on. Opt for “Fresh Air Fan Interlock” mode to prioritise fresh air circulation; regardless of whether the ducted system is turned on. In this mode, the Lossnay System will override a ducted system that is turned off and automatically activate the system’s Fan Mode. As a result fresh air continues to efficiently circulate throughout the home. DUCTED Supplies fresh (warmed or cooled) air into the home and helps control the build-up of moisture. Extracts stale air from the home, removing toxins, unwanted pollutants, and managing humidity. Returns room air to the Ducted Unit. Receives the pre-warmed (or cooled) fresh air from the Lossnay Unit and can then further heat or cool the fresh air as desired. Outside air is passed through the Lossnay Core allowing the air to be pre-warmed in winter (or pre-cooled in summer), using the energy recovered from the extracted stale air. Supplies Fresh Air Extracts Stale Air Returns Air Ducted Unit Lossnay Unit Combine a Ducted System with Fresh Air Heat Recovery Ventilation Maximise comfort by combining our ducted system with Lossnay Balanced Pressure Ventilation. Mitsubishi Electric Lossnay Ventilation can be integrated with a PEAD Ducted Heat Pump System offering a complete home heating, cooling and ventilation solution. The Lossnay Balanced Pressure Ventilation System recovers heat from the stale, damp air it extracts from your home – and then uses that energy to pre-warm or pre-cool the incoming filtered fresh air. This means that when Lossnay is combined with your ducted system, your home can be brought to the desired temperature faster because the heating system is not required to work as hard to do so. By having a well-ventilated home the air is also much drier, further speeding up the efficient heating process. In addition, because fresh air is brought in from the outside and not from the attic, air quality is maximised. When these two systems are combined to work together, it will ultimately create a drier, healthier environment for you and your family. Heat Pump Ventilation Ducted Heat Pump + Ventilation Heating/Cooling - Fresh Outside Air - Filtered Air (dust etc. removed) Energy Efficient Heat/Energy Recovery (Heat Exchange) - Supplies fresh heated air Lossnay Ventilation Unit Extracts air Return air Note: Each unit requires its own Wi-Fi Interface to enable Wi-Fi Interlock Control.
4 Fresh air is introduced into your home Stale air is removed from your home Stale indoor air is expelled outside Fresh air is introduced from outside Outdoors Indoors The Lossnay Core Recovers Energy to Pre-warm or Pre-cool Incoming Fresh Air Lossnay’s unique Heat Recovery Technology collects up to 92% of the heat energy in outgoing air to pre-warm or pre-cool the incoming fresh air. Energy Efficient, Save on your Power Bill*1 With Lossnay’s Heat Recovery Technology, less additional heating/cooling of incoming air is required to achieve your ideal home temperature – saving you money. Moisture and Condensation Control Effectively reduces moisture in your home by directly removing stale air that causes condensation. Automatic Free Cooling*2 Mode When specific conditions are met*3, Lossnay will automatically enter Automatic Free Cooling Mode. As a result, cooler fresh air is introduced and stale air is extracted, bypassing the Lossnay Core. This is ideal for cooling down a dwelling that may have overheated during the day, once the outside temperature has dropped in the evening. Now You Can See and Feel the Lossnay Difference! The Lossnay Wi-Fi Control App lets you see by how many degrees Lossnay is pre-warming or pre-cooling your home and reminds you to clean the unit’s filters, maximising cost efficiency and health benefits. Fresh Air Without Open Windows Lossnay ensures a well-ventilated home without opening windows, enhancing safety and minimising outdoor noise for your family. Improved Air Quality By drawing in fresh outdoor air and not attic air, indoor air quality is improved as high levels of CO2, odours, pollen and other pollutants are removed – ideal for allergy and asthma sufferers. Whisper Quiet Operation From an ultra quiet 14dB*4, Lossnay is the ideal solution for residential homes and apartments where quiet comfort is key. Easy To Clean The standard filters can be removed for regular cleaning to keep the unit in optimal working condition. The Lossnay Difference The Mitsubishi Electric Lossnay System is a patented heat recovery ventilation solution that uses fresh air (not attic air) to ventilate your home. The system works by extracting stale air from inside your house and replacing it with allergen-reduced fresh air from outside. Furthermore, Lossnay also recovers heat energy from the outgoing stale air to pre-warm (or precool) the fresh air being drawn into your home. *2 In comparison to using a dedicated cooling device. The unit will continue to use a small amount of power to bring colder fresh air from outside. *1 Compared to the use of a 100% fresh air, conventional ventilation system. *4 VL-220CZGV-E on lowest fan speed. Measured at 1.5m. *3 Lossnay must be in Auto Mode, and the outdoor air is cooler than the desired set temperature inside your home.
5 *2 In comparison to using a dedicated cooling device. The unit will continue to use a small amount of power to bring colder fresh air from outside. *5 The outside ‘Fresh Air’ and the inside ‘Avg Temp’ air temperatures are measured by the built-in sensors that are centrally located in the main Lossnay Ventilation unit. Fresh Air Heat Recovery Ventilation for all Types of Applications In-Ceiling Solutions These ducted whole home balanced pressure Lossnay Heat Recovery Ventilation Systems are designed for installation in homes that have available roof or attic space to accommodate the heat exchanger and corresponding ducting. Vertical Solutions The slimline, Vertical Lossnay Series features a small, upright footprint that can be placed in the garage or a utility cupboard and is not limited to an in-roof installation. Ventilating your home is vital as it maintains air quality and reduces moisture, creating a healthier and more comfortable environment. There is a Lossnay solution to suit most New Zealand homes, from whole home ducted to single room applications. Lossnay is specifically designed for more airtight homes built to the current New Zealand Building Code; delivering the optimum amount of fresh air without creating draughts and minimising indoor temperature fluctuations. In-Ceiling Single Room Solutions This cost effective ventilation system is specifically designed to provide fresh filtered air to a single room with the additional benefit of energy efficient heat recovery at the same time. The ducted design means the system can be installed in the roof or attic space, so it is unobtrusive and hidden away. Wall Mounted Single Room Solutions This easy to install back-to-back wall mounted system is designed to provide cost effective energy recovery ventilation to one specific area in the home. The ductless design means the system is ideal for homes and buildings where there is no roof space to install a heat exchanger. Whole Home Ventilation Single Room Ventilation Make Heat Recovery Ventilation Visible – with Advanced Lossnay Wi-Fi Control Elevating air quality and maximising energy efficiencies has never been easier, because now the power is in your hands. See by how many degrees*5 Lossnay is pre-warming or pre-cooling your home in real time, helping you save on your power bill because less additional heating is required to get a room up to temperature. And in summer, monitor by how many degrees Lossnay can reduce the average temperature in your home, using Automatic Free Cooling*2 Mode. The App will also proactively remind you when it is time to clean your filters to maximise both cost efficient operation and health benefits. Lossnay Wi-Fi Control truly is the smart evolution in fresh air ventilation. Note: Lossnay Wi-Fi Control comes standard with the Vertical Lossnay Series, and as an option for the LGH ranges. Note: Single room systems are not interlock compatible.
6 Features Temperature Sensor With an inbuilt thermostat (PAR-ZC01ME-E wall controller), the Zone Controller allows the actual usable space temperature to be measured, offering a more realistic and timely temperature measurement where it is needed most. Occupancy Sensor The Zone Controller (via the PAR-ZC01ME-E wall controller) constantly monitors the usable area to detect vacancy. Once detected, one of four user defined energy-save control options can be implemented to reduce energy consumption: turn the unit on/ off, lower the fan speed, temperature offset, or turn user designated zones on/off. Brightness Sensor Working in conjunction with the Occupancy Sensor, the Brightness Sensor can be set to maximise energy savings when it detects user defined “Light” or “Dark” conditions (lux values). Backlit LCD Touch Screen Featuring a liquid-crystal display (LCD), back lit for operation in dark conditions. For ease of use, the user defined coloured LED indicator (at the bottom of the controller) lights up to indicate the current operation mode i.e. red for Heating, blue for Cooling, green for Night Setback. Intuitive Airflow Control Where traditional ducted systems require manual adjustment of the indoor fan speed, the PAC-ZC40/80, equipped with the exclusive Mitsubishi Electric Intuitive Airflow Control, intuitively detects which zones you have open/closed and adjusts the fan speed accordingly. When zones are not in use the fan speed is lowered automatically, leading to increased overall energy savings. Advanced temperature monitoring and management. Now you can control, monitor and schedule which zones your ducted heat pump is controlling in real time from anywhere via your smart phone, tablet or online account. Zone Controller Optional Wi-Fi Control Zone Control will enable your Mitsubishi Electric Ducted Central Heat Pump System to program and control either up to 4 or up to 8 individual zones, providing heating or cooling only to the rooms that require it. Built-in sensor functions monitor room temperature, brightness and occupancy to maximise energy efficient use of the whole system throughout the home or just those rooms where it is needed.* * Allows connection of up to 2x optional thermistors (PAC-SE41TS-E).
7 Specifications Specifications: Fresh Air Home Ventilation Type In-Ceiling Concealed Ducted Vertical Wall Mounted Ducted Model VL-220CZGV-E VL-250CZPVU-L/R-E VL-350CZPVU-L/R-E VL-500CZPVU-L/R-E Ventilation Modes Heat Recovery Mode Heat Recovery Mode Heat Recovery Mode Heat Recovery Mode Heat Exchange System Heat Recovery Ventilating System Heat Recovery Ventilating System Heat Recovery Ventilating System Heat Recovery Ventilating System Heat Exchange Material Water-Resistant Paper Sensible Heat Exchanger Synthetic Resin Sensible Heat Exchanger Synthetic Resin Sensible Heat Exchanger Synthetic Resin Sensible Heat Exchanger Surrounding Air Condition Between 0°C and 40°C, 80%RH or less Indoor temperature and humidity should not exceed the dew point temperature 12°C Indoor temperature and humidity should not exceed the dew point temperature 12°C Indoor temperature and humidity should not exceed the dew point temperature 12°C Return (Suction) Air Condition Up to 40°C, 95%RH Up to 40°C, 95%RH Up to 40°C, 95%RH Up to 40°C, 95%RH Supply Fan Operation Under Low Outdoor Temperature 0°C to -5°C: Intermittent operation 24 min ON, 6 min OFF. -5°C or less: Continuous supply air stopped. -3°C to -15°C: Intermittent operation. -15°C or less: Continuous supply air stopped -3°C to -15°C: Intermittent operation. -15°C or less: Continuous supply air stopped -3°C to -15°C: Intermittent operation. -15°C or less: Continuous supply air stopped Electrical Power Supply 220-240V / 50Hz 220-240V / 50Hz 220-240V / 50Hz 220-240V / 50Hz Fan Speed Fan Speed 4 Fan Speed 3 Fan Speed 2 Fan Speed 1 Fan Speed 4 Fan Speed 3 Fan Speed 2 Fan Speed 1 Fan Speed 4 Fan Speed 3 Fan Speed 2 Fan Speed 1 Fan Speed 4 Fan Speed 3 Fan Speed 2 Fan Speed 1 Input Power (W) 80 35 18.5 8.5 106 44 23 11 155 71 37 19 275 104 49 21 Air Volume - Heat Recovery Mode (m3/h) 230 165 120 65 250 175 125 75 320 224 160 96 500 350 250 150 (L/s) 64 46 33 18 69 49 35 21 89 62 44 27 139 97 69 42 External Static Pressure (Pa) 164 84 44 13 150 74 38 14 150 74 38 14 200 98 50 18 Temperature Exchange Efficiency (%) 82 84 85 86 85 87 88 90 85 87 88 90 85 87 89 92 Noise (dBA) (Measured at 1.5m under the centre of the unit in an anechoic chamber) 31 25 19 14 31 22 16 15> 35 26 19 15> 37 29 22 15> Duct Size (mm) 150 122 145 183 Interlock Cable Included (CN2L) No Yes Yes Yes Dimensions W x D x H (mm) 850 x 720 x 320 595 x 356 x 565 658 x 432 x 623 725 x 556 x 632 Weight (kg) 31 26 32 39 VL Whole Home Range Specifications: Ceiling-Concealed (PEAD) REFRIGERANT R32 Indoor Unit PEAD-M50 PEAD-M60 PEAD-M71JAA PEAD-M100JAA PEAD-M125JAA PEAD-M140JAA Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.-max.) (kW) 5.0 (2.3-6.2) 6.0 (1.7-7.4) 6.0 (2.3-6.5) 7.0 (2.8-8.0) 7.1 (2.8-8.1) 8.0 (2.6-10.2) 10.0 (4.9-11.4) 11.2 (4.5-14.0) 12.5 (5.5-14.0) 14.0 (5.0-16.0) 14.0 (6.2-15.3) 16.0 (5.7-18.0) Power Input (kW) 1.33 1.44 1.72 1.85 1.98 2.00 2.67 2.80 3.66 3.52 4.37 4.18 Rated EER/COP 3.75 4.16 3.48 3.78 3.58 4.00 3.74 4.00 3.41 3.97 3.20 3.82 Rated AEER/ACOP 3.70 4.09 3.43 3.72 3.53 3.93 3.61 3.86 3.32 3.86 3.13 3.73 Power Supply Outdoor Unit 230V, Single-phase, 50Hz Airflow (m3/h) 12 - 14.5 - 17 14.5 - 18 - 21 1051-1260-1501 1440-1738-2041 1771-2131-2520 1918-2340-2761 (L/s) 200 - 242 - 283 242 - 300 - 350 292-350-417 400-483-567 492-592-700 533-650-767 External Static Pressure (Pa) 35/50/70/100/125 Sound Pressure Level (dBA) 30 - 35 - 39 30 - 32 - 36 30-33-38 33-38-42 36-40-44 40-44-49 Dimensions W x D x H (mm) 900 x 732 x 250 1,100 x 732 x 250 1,400 x 732 x 250 1,600 x 732 x 250 Weight (kg) 26 29 30 39 40 44 Outdoor Unit SUZ-M50VAD SUZ-M60VAD SUZ-M71VAD PUZ-ZM100VKA2 PUZ-ZM125VKA2 PUZ-ZM140VKA2 Dimensions Height (mm) 714 880 1,338 Width (mm) 800 840 1,050 Depth (mm) 285 330 330 (+40) Weight (kg) 41 54 55 114 Operation Range Outdoor Cooling [°C] -15 ~ 52 -5 (-15*) / 52 Heating [°C] -15 ~ 24 -20 / 21 *With optional air protection guide Ducted PEAD Series
8 Specifications: Fresh Air Home Ventilation Type In-Ceiling Concealed Ducted Model LGH-15RVX3-E LGH-25RVX3-E LGH-35RVX3-E LGH-50RVX3-E Ventilation Modes Energy Recovery Mode, Bypass Ventilation Mode Energy Recovery Mode, Bypass Ventilation Mode Energy Recovery Mode, Bypass Ventilation Mode Energy Recovery Mode, Bypass Ventilation Mode Heat Exchange System Energy Recovery Ventilation System Energy Recovery Ventilation System Energy Recovery Ventilation System Energy Recovery Ventilation System Heat Exchange Material Specially Treated Paper Plate Heat Exchanger Specially Treated Paper Plate Heat Exchanger Specially Treated Paper Plate Heat Exchanger Specially Treated Paper Plate Heat Exchanger Surrounding Air Condition Between 0°C and 40°C, 80%RH or less Between 0°C and 40°C, 80%RH or less Between 0°C and 40°C, 80%RH or less Between 0°C and 40°C, 80%RH or less Return (Suction) Air Condition Up to 40°C, 80%RH Up to 40°C, 80%RH Up to 40°C, 80%RH Up to 40°C, 80%RH Supply Fan Operation Under Low Outdoor Temperature -10°C to -15°C: Intermittent opperation 60 min ON, 10 min OFF. -15°C or less: Intermittent operation 55 min OFF, 5 min ON. -10°C to -15°C: Intermittent opperation 60 min ON, 10 min OFF. -15°C or less: Intermittent operation 55 min OFF, 5 min ON. -10°C to -15°C: Intermittent opperation 60 min ON, 10 min OFF. -15°C or less: Intermittent operation 55 min OFF, 5 min ON. -10°C to -15°C: Intermittent opperation 60 min ON, 10 min OFF. -15°C or less: Intermittent operation 55 min OFF, 5 min ON. Electrical Power Supply 220-240V / 50Hz 220-240V / 50Hz 220-240V / 50Hz 220-240V / 50Hz Fan Speed Fan Speed: High Fan Speed: Low Fan Speed: High Fan Speed: Low Fan Speed: High Fan Speed: Low Fan Speed: High Fan Speed: Low Input Power (W) 55 10 75 11 120 15 185 15 Air Volume - Heat Recovery Mode (m3/h) 150 38 250 63 350 88 500 125 (L/s) 42 10 69 17 97 24 139 35 External Static Pressure (Pa) 120 8 120 8 160 10 150 10 Temperature Exchange Efficiency (%) 73.5 81.5 75.5 88.0 75.0 82.0 70.5 75.0 Noise (dBA) (Measured at 1.5m under the centre of the unit in an anechoic chamber) 27.0 17.0 30.5 17.0 30.5 17.0 35.0 17.0 Duct Size (mm) 100 150 150 200 Interlock Cable Included (CN2L) Yes Yes Yes Yes Dimensions W x D x H (mm) 780 x 610 x 289 780 x 735 x 289 888 x 874 x 331 888 x 1,016 x 331 Weight (kg) 20 22 30 33 Note: Other models of the LGH Range are available (air volume from 38–2,000 m3/h). LGH Whole Home Range Lossnay VL100 Single Room Range Specifications: Single Room Ventilation Type Wall Mounted Single Room In-Ceiling Single Room Model VL-100EU5-E VL-100ZSKRT-E Ventilation Modes Energy Recovery Mode Energy Recovery Mode Heat Exchange System Energy Recovery Ventilation System Energy Recovery Ventilation System Heat Exchange Material Specially Treated Paper Plate Heat Exchanger Specially Treated Paper Plate Heat Exchanger Surrounding Air Condition Between -10°C and 40°C, 80%RH or less Between -10°C and 40°C, 80%RH or less Return (Suction) Air Condition Up to 40°C, 80%RH Up to 40°C, 80%RH Electrical Power Supply 230V / 50Hz 230V / 50Hz Fan Speed Fan Speed: High Fan Speed: Low Fan Speed: High Fan Speed: Low Input Power (W) 31 15 32 15 Air Volume - Heat Recovery Mode (m3/h) 105 60 78 42 (L/s) 29.1 16.6 21.7 11.7 Temperature Exchange Efficiency (%)* 73 80 49 62 Noise (dBA) (Measured at 1.5m under the centre of the unit in an anechoic chamber) 37 25 40 25.5 Duct Size (mm) - 100 Dimensions W x D x H (mm) 620 x 200 x 265 Unit: 386 x 386 x 204 Grille: 455 x 455 x 9 Weight (kg) 7.5 6 *In Heating Mode. PUBLISHED JUN 2024 www.mitsubishi-electric.co.nz | 0800 784 382 Please note: When deciding on the best place to position the Lossnay Ventilation System, care needs to be taken to not have incoming air intake near or close to a wood burner flue.
